| Woofer Size | 165 mm |
| Tweeter Size | 28 mm |
| Woofer Voice Coil Diameter | 30 mm |
| Tweeter Voice Coil Diameter | 28 mm |
| Magnet Size Woofer | 90 x 40 x 15 |
| Power Handling – Peak | 250 W |
| Power Handling – Continuous | 125 W |
| Sensitivity | 91 dB |
| Impedance | 4 Ohm |
| Frequency Response | 50 ÷ 22k |
| Crossover Woofer | Lo/Hi-Pass 2.5 kHz @ 12/12 dB/Oct. |
| Adjustment Tweeter Level | +2; 0; -2 dB |
| Woofer Cone Diameter | 130 mm |
| Xmax Woofer | 3 mm |
ESPECIFICACIONES ELÉCTRICO-ACÚSTICAS
| Re Woofer | 3.5 Ohm |
| Fs Woofer | 68 Hz |
| Le Woofer mH @ 1 kHz | 0.31 |
| Vas Woofer | 8.2 l |
| Mms Woofer | 16.1 g |
| Cms Woofer | 0.34 |
| Bxl Woofer | 5.5 |
| Qts Woofer | 0.74 |
| Qms Woofer | 7.84 |
| Spl Woofer | 91 dB |
GENERAL
| Weight Woofer | 1.2 kg |
| Weight Tweeter | 0.07 kg |
